•STRUCTURE
Earth quake resistant – Fe 550 TMT bar – Red brick/Fly Ash brick walls – OPC 53 for RCC and
PPC 43 grade cement for other works.
Gypsum board false ceiling for Living/ dining and all Bed rooms.
Basement height 2’.6”.
•FLOORING
Vitrified tiles from Kajaria/ Somany/ Equivalent, 4’ x 2’ for living and dining (Rs.100 per sft)and
2’ X 2’ for bedrooms and kitchen (Rs.50 per sft)
Exterior vitrified tiles for car park and interlocking Paver blocks for setback areas.
Heat Resistant Tiles for the Terrace of make Insulla/ Equivalent
• TOILET AND UTILITY
Kajaria/Somany/Equivalent tiles 24”x12”/18”x12” Rs.50 per sft for Toilets, Kitchen, Utility
walls and 12”x12” Rs.40 for floor.
Epoxy grouting for tiles, with waterproofing (Sunken areas) in Utility and Toilets.
•SANITARY AND PLUMBING
CPVC for concealed line, and UPVC open pipeline for fresh water and PVC pipeline for sanitary
and Kitchen of Finolex/Equivalent.
Wall mounted closet with concealed tank of Jaquar/Toto/Equivalent.
Taps and fittings will be CP of make Jaquar/Equivalent
• KITCHEN
Black galaxy granite for counter and Stainless steel sink with drain board of Niralli/Equivalent.
Shelves with 4 Nos of Black Granite
• ELECTRICAL
Chemical earthing – M.S. fabricated powder coated Panel Board, Independent DB with circuit
Breakers and RCCB. FRLS cables from ORBIT/RR/Q-Flex/Power flex/Equivalent &-
Legrand/Equivalent Modular switches, with Adequate 5 amps and 15 amps points
• JOINERIES
DOORS
3’ 6"x 7’ First quality African teak, with 5”x3” for frame and 1 ½” thick planks for Main door
3’x 7' First quality African teak frames and Skin molded doors for Bedrooms
2’.6” x 7' First quality African teak frames and ABS both side painted doors for toilets.
All Hardware will be Stainless steel.
• PAINTING
Internal walls will be two coats of cement based Putty, and two coats of premium Emulsion
with one coat of Primer of Asian/Equivalent
External surface will be Texture, Exterior primer and two coats of Apex grade emulsion of
Asian/Equivalent.
Main door will be polished with melamine spray.
• WINDOWS
UPVC sliding for kitchen and Open able for other windows with 5 mm plain glass and 12 mm
Bright bar gills embedded in to the wall.
French door will be sliding with toughened glass.
2’ x 2’ UPVC fixed louver for ventilator with exhaust fan provision for toilets.
• OHT AND UG SUMP
4 ½” Outer brick wall and RCC inner wall with water proofing and bifurcation for Metro water
and bore water and 12000 liters RCC wall with water proofing for UG sump.
6” dia Bore well as per the water level in the area will be provided
• LIFT
6 (SIX) Passenger Auto door lift MS finish lift from EMPEROR/ Equivalent with License.
• GENERATER
Generator will be provided to support Lift, Common lights, Pumps and Light & fan points to
the inside of flat.
• PEST CONTROL
Anti termite pest control treatment will be done at footing, around plinth beam, Brickwork
and paving block laying stages.
• Common Ammonites
• CCTV
• Access control system with glass door
• Piped gas
• SS Staircase railing
• Landscape
• Seating arrangement at terrace and car park
• Granite for steps and Landing in Common staircase
• Compound wall with One gate & wicket gate at front side
• Name board
• Party table with wash basin at terrace
• Pandal rings at terrace
• Pressure booster pump
• granite putty in window bottom jams
• Electrical charger in car park area
• Elegant elevation features.
